HATS™ & HATS²™ Test Services

HATS²™ Single Via*, Custom Coupons & IPC-2221B "D" coupon Reliability & Robustness testing can be performed at the HATS²™ test service partners that are highlighted on the map below. Hover your mouse over the location to see contact details. Convection reflow simulation per IPC-TM-650 2.6.27 (Thermal Stress, Convection Reflow Assembly Simulation) is done in a HATS²™ Tester where resistance is monitored during simulated reflow cycles.

Original HATS™ Coupons can be tested at both HATS™ & HATS²™ test service partners. Prior to thermal cycling, the test coupons may also be subjected to convection reflow simulation in either a standard reflow oven (for the original HATS™ Tester) or in a HATS²™ Tester where resistance is monitored during simulated reflow cycles.
Each HATS²™ Testing Order must be accompanied by a HATS²™ Test Request Form. This Form is a Microsoft Word Form that must be totally completed as the input from this form is used to generate the information found in the HATS²™ Test Report.

Please click here to Download HATS²™ Test Request Form


HATS™ & HATS²™ Test Service Providers Worldwide

Lorem ipsum dolor sit amet, sapien platea morbi dolor lacus nunc, nunc ullamcorper. Felis aliquet egestas vitae, nibh ante quis quis dolor sed mauris. Erat lectus sem ut lobortis, adipiscing ligula eleifend, sodales fringilla mattis dui nullam. Ac massa aliquet.
Stacks Image 2347

Microtek Laboratories China
No.19, Xinke Road
E-Park New District
Changzhou, Jiangsu 213031 China
Tel. +86-519-84587805
Fax +86-519-85487810

Stacks Image 241

Element Materials Technology
1435 S Allec Street
Anaheim, CA 92805
Tel. +1-714-999-1616

Stacks Image 231

159 Yigal Alon St.
Tel Aviv 6744367, Israel
Tel. +972-369-62132
Fax +972-369-62131

* U.S. Patent 10,379,153. German Patent 10 2019 006 553.0. Japanese Patent 7,291,045. Chinese Patent ZL 201922142627.1. Worldwide Patents Pending.
